Cable trays and cable glands are useful and practical electrification solutions for equipping workstations.
They can be used for both individual and multi-user workstations. The available colors (which vary depending on the product) allow them to be matched with the different finishes in our furniture ranges.
Media
Finishes
-
-
Aluminum
-
White
-
Black
-
Features
Technical description
- GUTTERS
- Made from 8/10th thick sheet steel.
- Different models are available to equip individual workstations as well as multi-workstations.
- Cable trays allow for cable routing and storage of socket boxes
- Universal cable trunking
with slots for cable management and routing. The trunking can be joined end-to-end by simply slotting it into the other.
Secured with wood screws under melamine panels.
Available in Aluminum, White, and Black finishes. - Simple gutter for modesty panels.
Fixing to Structurex® melamine-faced structural modesty panels or to vertical panels using wood screws.
Available in aluminum finish only. - Single and double cable trays.
Fixing via wood screws or metal inserts (depending on the version) under the melamine worktops.
Available in the following finishes:
Aluminum, White, and Black for the single tray.
Only available in Black for the double tray. - UNIVERSAL CABLE HOOKS
- These cable management clips allow cables to run under tabletops and can be used as cable trays on melamine legs.
Two models are available: 4 rings (screws not included) and 6 rings (screws and adhesive included).
They attach to melamine panels with wood screws.
Available in an aluminum finish only. - CPU SUPPORT
- Adjustable bracket to accommodate PCs with dimensions ranging from 33 to 63 cm in height and 8 to 23 cm in width.
Secures with wood screws under melamine shelves.
Maximum load 38 kg.
Available in aluminum, white, and black finishes. - CABLE DOWNS
- Different models are available for equipping fixed workstations, such as height-adjustable workstations.
- Cable drops allow cables to be routed from the platforms to the ground.
- Cable drops for arch base.
Magnetic metal vertical cable drop for arch base.
Available in Aluminium, White and Black finishes.
- Cable management systems for height-adjustable bases.
Extendable cable management system . Made of ABS with a weighted base. Extends up to 150 cm. Attaches under tabletops with wood screws.
Available in white and black finishes.
Magnetic cable management system with links for single and multi-user desks.
Magnetic profile, 40 cm high, on the base + 28 links.
Attaches under tabletops with wood screws.
Available in aluminum, white, and black finishes.
Magnetic cable management system with links for multi-user desks with a central cable tray only.
Magnetic link + 32 links.
Attaches to the central cable tray with a magnet and under tabletops with wood screws.
Available in aluminum, white, and black finishes. - Cable management systems for fixed bases.
Articulated cable management system . Universal articulated PVC cable management system.
Attaches under tabletops with wood screws.
Available in Aluminum, White, and Black finishes.
Vertical zip cable management system.
Braided polyester sheath Ø 25 mm, fire-retardant, Black finish only. - Cable trays.
Link cable tray . 50-link cable tray.
Magnetic adapter for mounting on metal bases.
Allows you to guide up to 20 cables.
Available in Aluminum, White, and Black finishes.
Metal profile
. Double-sided adhesive fixing.
Allows you to guide up to 25 cables.
Available in Aluminum, White, and Black finishes.
Technical drawings
